Pioneer 1000-5 EPS > Honda ATV & Side-by-Side Canada Main content
MSRP
starting from
$
24,499
Key Features
Engine & Drivetrain
Chassis & Suspension
Additional Features
Key Features Modal
Use of this product must comply with all rules and regulations applicable to the region in which the product is used. Please consult your local dealer for more information.
Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S. or European models. Canadian specifications and models may vary.
Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S. or European models. Canadian specifications and models may vary.
Engine & Drivetrain
-
Powerful Performance
We’ve given the engine huge power in our entire Pioneer 1000-5 lineup, especially in the midrange and top end. And thanks to the lower gear ratios, you’ll feel quick acceleration and stellar overall performance. Using the same Unicam® cylinder head design found in our motocross bikes, the class-leading 999cc liquid-cooled inline twin is compact, while delivering the kind of horsepower and torque you’d expect from a flagship model.Use of this product must comply with all rules and regulations applicable to the region in which the product is used. Please consult your local dealer for more information.
Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S. or European models. Canadian specifications and models may vary. -
Dual Clutch Transmission (DCT)
Drive the way you want, with the industry’s first and only six-speed Dual Clutch Transmission. Choose between manual mode or fully automatic. Plus, the addition of Sport Mode increases the fun, shifting at higher RPM for a spirited, full-performance driving experience.Use of this product must comply with all rules and regulations applicable to the region in which the product is used. Please consult your local dealer for more information.
Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S. or European models. Canadian specifications and models may vary. -
Advanced Transmission Logic
The brain of the DCT, Advanced Transmission Logic, senses how you drive and adapts. Relaxed drivers get earlier shifts for a quieter ride at lower engine speeds. Sportier drivers will hold each gear longer for higher RPM shifts. And when going downhill, you get true engine braking. Now that’s a smart transmission.Use of this product must comply with all rules and regulations applicable to the region in which the product is used. Please consult your local dealer for more information.
Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S. or European models. Canadian specifications and models may vary. -
Paddle Shifting
Steering column-mounted paddle shifters add a serious dose of performance in every drive. In Manual mode, they let you shift without ever taking your hands off the wheel, and in Automatic mode, they let you override the current gear with a quick up or downshift, holding that gear for several seconds before returning to Automatic mode.Use of this product must comply with all rules and regulations applicable to the region in which the product is used. Please consult your local dealer for more information.
Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S. or European models. Canadian specifications and models may vary. -
Tackle Any Terrain
Venturing over really tricky, rocky terrain, hauling a big load down a steep hill, or need some real hill-climbing ability? The high/low-range sub transmission provides a full 42-percent gear reduction when you switch to the low range.Use of this product must comply with all rules and regulations applicable to the region in which the product is used. Please consult your local dealer for more information.
Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S. or European models. Canadian specifications and models may vary. -
Clever Controls
Quickly and easily choose, via a dash-mounted lever, from 2WD, 4WD, 4WD with differentials locked for the toughest conditions, or Turf mode; perfect for sensitive surfaces like grass fieldsUse of this product must comply with all rules and regulations applicable to the region in which the product is used. Please consult your local dealer for more information.
Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S. or European models. Canadian specifications and models may vary.
Chassis & Suspension
-
Electric Power Steering
Honda pioneered (no pun intended) electric power steering on our side-by-sides. And we’ve never stopped making it better. Every Pioneer 1000-5 features an EPS system with a brushless motor integrated with the ECU. The return-to-centre function makes it intuitive on straight trails, and the whole system feels responsive and linear.Use of this product must comply with all rules and regulations applicable to the region in which the product is used. Please consult your local dealer for more information.
Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S. or European models. Canadian specifications and models may vary. -
Independent Suspension
Dual A-arm suspension gives you 10.5 inches of travel in the front, and 10-inches of travel in the rear. Pair that with stellar ground clearance, and you maximize available traction and superior comfort maneuvering over terrain other side-by-sides would shy away from.Use of this product must comply with all rules and regulations applicable to the region in which the product is used. Please consult your local dealer for more information.
Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S. or European models. Canadian specifications and models may vary. -
Superior Stopping Power
With a side-by-side this powerful and capable, you need brakes that are up to the job, too. Honda’s extensive automotive experience means you know the all-wheel disc brake system is up to the task.Use of this product must comply with all rules and regulations applicable to the region in which the product is used. Please consult your local dealer for more information.
Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S. or European models. Canadian specifications and models may vary.
Additional Features
-
QuickFlipTM Seats
Experience ultimate flexibility in seating options. In addition to the comfortable three passenger contoured bench seat up front, the bed incorporates a pair of QuickFlipTM seats that flip up or fold down independently in seconds. Up, they provide secure seating for one or two additional passengers; down, you get a flat cargo bed for utility use.Use of this product must comply with all rules and regulations applicable to the region in which the product is used. Please consult your local dealer for more information.
Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S. or European models. Canadian specifications and models may vary. -
Powerful Towing
You can load a full half-ton (1,000 lb.) into the bed. And when it’s time to unload, the bed’s hydraulic-assisted tilting feature makes dumping firewood, gravel, feed or other items easy. And because it’s able to tow a full ton (more than 2,500 lb.) – with a hitch mount – the Pioneer 1000 can take on big jobs that otherwise would require a tractor or a truck.Use of this product must comply with all rules and regulations applicable to the region in which the product is used. Please consult your local dealer for more information.
Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S. or European models. Canadian specifications and models may vary. -
Secure Design
The Occupant Protection Structure uses large-diameter tubing and includes integrated handholds, recessed top tubes and a more spacious structure to enhance protection. Hard doors and roll-up side nets provide a secure feel and keep mud and debris out of the cabin, while automotive-style three-point belts with an Emergency Locking Retractor mechanism help keep everyone secure.Use of this product must comply with all rules and regulations applicable to the region in which the product is used. Please consult your local dealer for more information.
Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S. or European models. Canadian specifications and models may vary. -
LCD Instrument Display
The instrument display is easy to read, with big and bright graphics. The display includes a clutch indicator and a battery-voltage readout too, in addition to speed, fuel level, RPM, transmission mode, water temperature, trip information and more.Use of this product must comply with all rules and regulations applicable to the region in which the product is used. Please consult your local dealer for more information.
Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S. or European models. Canadian specifications and models may vary. -
Prewired for Accessories
We’ve pre-wired all Pioneer 1000 models for accessory switches, so you don’t have to run a lot of extra wiring. For things like a winch alone, it slashes installation time as well as making the installation easier and cleaner. We’ve even included an extra, integrated grounding terminal.Use of this product must comply with all rules and regulations applicable to the region in which the product is used. Please consult your local dealer for more information.
Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S. or European models. Canadian specifications and models may vary. -
Accessory Switch Panel
Standard equipment on the Pioneer 1000, the switch panel has room for seven switches, letting you control things like a winch, accessory lights, and more. A fully integrated design, it sits in the centre of the dashboard, underneath the other switches and controls.Use of this product must comply with all rules and regulations applicable to the region in which the product is used. Please consult your local dealer for more information.
Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S. or European models. Canadian specifications and models may vary.
Colours
Patriot Red
2023 Deluxe
MSRP
starting from
$24,499
Colours
Patriot Red
2023 Deluxe
MSRP
starting from
$24,499
Model Colours Modal
![empty]()
Gallery
Gallery
Model Gallery Modal
![empty]()
Honda Canada Inc. reserves the right to make changes at any time, without notice or obligation, to colours, specifications, accessories, materials and models. Some vehicles shown may be US or European models or have optional equipment – features and equipment depicted are believed to be correct but accuracy cannot be guaranteed. Canadian specifications and models may vary.
Specifications
Engine & Drivetrain
Engine Type
Liquid-cooled longitudinally mounted parallel-twin cylinder
Displacement
999 cc
Bore & Stroke
92 mm x 75.1 mm
Compression Ratio
10.0:1
Valve Train
Unicam, 4 valves
Fuel Delivery
PGM-FI electronic fuel injection with 44 mm throttle body
Transmission
Fully automatic, Six-speed plus reverse Dual Clutch Transmission with Sport Mode and Manual Mode with Paddle Shifting. High/Low Range Sub-transmission. Four drive modes include Turf, 2WD, 4WD, and 4WD with differential lock.
Power Steering
Standard
Final Drive
Direct front and rear driveshafts
Chassis & Suspension
Front Suspension
Independent double-wishbone; 268 mm (10.6 in) travel
Rear Suspension
Independent double-wishbone; 254 mm (10 in) travel
Additional Information
Tires
Front: 27 x 9 - 14
Rear: 27 x 11 - 14
Rear: 27 x 11 - 14
Brakes
Front: Dual 210 mm discs
Rear: Dual 210 mm discs
Rear: Dual 210 mm discs
Towing Capacity
1,134 kg (2,500 lb)
Length
3,037 mm (119.6 in)
Width
1,599 mm (63 in)
Height
1940 mm (76.4 in)
Ground Clearance
312 mm (12.3 in)
Wheelbase
2,038 mm (80.2 in)
Curb Weight
790 kg (1,742 lb)
Cargo capacity
454 kg (1,000 lb)
Fuel Capacity
30.0 liters, including 6.4-liter reserve
Colour
Patriot Red
Warranty
12 months, unlimited mileage, freely transferable warranty; extended coverage available with Honda Plus
†
