TRX420 Rancher > Honda ATV & Side-by-Side Canada Main content
Engine & Drivetrain
Engine & Drivetrain
Chassis & Suspension
Chassis & Suspension
Additional Features
Additional Features
Engine & Drivetrain
  • Efficient engine
    Rugged liquid-cooled 420 cc longitudinally mounted engine allows direct driveshaft alignment to both front and rear wheels for maximum drivetrain efficiency. Programmed Fuel Injection (PGM-FI) system improves power delivery and throttle response, and increases fuel efficiency for extended range.
  • Broad powerband
    Overhead-valve design provides compact engine dimensions for improved ground clearance while maintaining a broad, easy-to-use powerband.
  • Reduced vibration
    Rubber-cushion engine mounting and gear-driven counter-balancer reduce vibration.
  • Easy start
    Convenient electric starting, with an automatic internal-decompression system, gets you going quickly. Also equipped with a recoil starter as back-up.
  • Tough transmission
    Rugged five-speed transmission with foot shifter and automatic clutch lets you precisely choose the gear you need. Super-heavy-duty automatic clutch with low-rpm engagement provides excellent drivability and towing capacity.
  • Convenient selector
    Handy 4WD/2WD selector lever, mounted on the left-front panel, engages 4WD when needed for the tough stuff and 2WD when conditions allow.
  • Strong output
    Powerful alternator has 416 watts of output available.
  • Quiet operation
    Stainless-steel exhaust system includes a USDA- qualified spark arrester/muffler designed for quiet operation without servicing for long-lasting performance.
Chassis & Suspension
  • Adjustable suspension
    Adjustable spring preload featured on all shocks allows suspension tuning to match varying loads and riding conditions. Double-cradle steel frame developed with Computer Aided Engineering features increased stiffness for even more precise handling and a smoother ride.
  • Precise handling
    Tough, large-diameter 24-inch front and rear tires provide excellent ground clearance of 183 mm (7.2 in.) while maintaining great handling characteristics. Front and rear suspension feature 170 mm (6.7 in.) of travel at both ends for a plush and controlled ride.
  • Trail ready
    Enclosed-axle type swingarm optimizes stiffness for improved toughness and durability, and excellent handling performance. Rubber swingarm pivot bushings provide increased low-speed ride comfort and extra durability.
  • Durable design
    Plastic CV joint boots are durable and tear- resistant with sealed steering-knuckle bearings for extended durability. Steering-mechanism design allows a tight turning radius for excellent manoeuvrability.
  • Stopping power
    "Large 190 mm dual front hydraulic disc brakes provide strong, consistent stopping power. Rear drum brake is located inside the right rear wheel for improved durability and increased ground clearance."
Additional Features
  • Rugged design
    Durable bodywork offers excellent mud and debris protection. Full-length synthetic lower skidplate with integrated front brush guard provides extra protection against damage from rocks, sticks or other obstacles.
  • Strong visibility
    Twin-headlight system features powerful 35-watt bulbs for improved light distribution.
  • Easy maintenance
    One-piece tank/side cover allows easy access for maintenance with no tools required.
  • Extended range
    Large fuel tank with 14.7-litre capacity (including a 4.9-litre reserve) provides extended range. Fuel pump derived from Honda automobile technology mounts in the fuel tank for better heat isolation and increased filter life.
  • Intuitive display
    Full-function instrumentation gives the dash a modern look while providing information at a glance. There’s even a Maintenance Minder system that notifies when it’s time for service.
  • New Pro Connect Rack System
    New Pro Connect Rack System for accessories. Mount accessories directly and quickly to the rear or front rack of your Rancher using easy Pro Connect Rack System (no tools required). Our purpose-built line of Pro Connect accessories keeps your gear in place and more secure wherever you place your items on the rack while maximizing bed storage. Front and rear steel-tube carriers feature large steel plates and additional tie-down points for improved load security.
  • Superior comfort
    Seat padding is both thick and soft for excellent comfort.
  • Powerful towing
    Heavy-duty trailer hitch with 385 kg (848 lb.) towing capacity.
  • Multi functional
    A host of optional accessories allow you to tailor your TRX Rancher® 420 to your needs.
Colours
Patriot Red TRX420
Patriot Red
2020 TRX420
MSRP starting from $7,699
Adventure Green TRX420
Adventure Green
2020 TRX420
MSRP starting from $7,699
Colours
Patriot Red TRX420
Patriot Red
2020 TRX420
MSRP starting from $7,699
Specifications
Engine & Drivetrain
Engine Type
Liquid-cooled longitudinally mounted single-cylinder 4-stroke
Displacement
420 cc
Bore & Stroke
86.5 mm x 71.5 mm
Compression Ratio
9.9:1
Valve Train
OHV, 2 valves
Fuel Delivery
PGM-FI electronic fuel injection
Transmission
Five-speed with automatic clutch, reverse and ultra-low first gear
Power Steering
Not Available
Final Drive
2WD/4WD; direct front and rear driveshafts with 2WD/4WD shifter and torque-sensing front differential
Front Suspension
Independent Double A-arm with adjustable hydraulic shocks; 170 mm (6.7 in.) travel
Rear Suspension
Swingarm with single adjustable hydraulic shock; 170 mm (6.7 in.) travel
Tires
Front: 24 x 8-12
Rear: 24 x 10-11
Brakes
Front: dual 190 mm hydraulic discs
Rear: 160 mm sealed mechanical drum
Length
2,103 mm (82.8 in.)
Width
1,205 mm (47.4 in.)
Ground Clearance
183 mm (7.2 in.)
Seat Height
856 mm (33.7 in.)
Wheelbase
1,270 mm (50.0 in.)
Curb Weight
279 kg (615 lb.) including required fluids and full tank of gas - ready to ride
Fuel Capacity
14.7 litres, including 4.9 litre reserve
Colour
Patriot Red, Adventure Green
Warranty
12 months, unlimited mileage, freely transferable warranty; extended coverage available with Honda Plus
