TRX500 Foreman ES EPS > Honda ATV & Side-by-Side Canada Main content
Engine & Drivetrain
Engine & Drivetrain
Chassis & Suspension
Chassis & Suspension
Additional Features
Additional Features
Engine & Drivetrain
  • Maximum efficiency
    Powerful liquid-cooled 475 cc four-stroke engine is longitudinally mounted, allowing direct driveshaft alignment to both front and rear wheels for maximum drivetrain efficiency.
  • Compact engine
    Overhead-valve design provides compact engine dimensions for improved ground clearance while maintaining a broad, easy-to-use powerband.
  • Reduced vibration
    Rubber-cushion engine mounting and gear-driven counter-balancer reduce vibration.
  • Easy start
    Convenient electric starting, with an automatic internal-decompression system, gets you going quickly and easily.
  • Fuel efficient
    Programmed Fuel Injection (PGM-FI) system improves power delivery and throttle response, and increases fuel efficiency for extended range.
  • Excellent drivability
    Super-heavy-duty automatic clutch with low-rpm engagement for excellent drivability and towing capacity.
  • Trail ready
    2WD/4WD system offers three drive modes: 2WD; 4WD with torque-sensing front differential; and 4WD with locked front differential to optimize traction. The system also features a Speed Override mode that can be engaged when the front differential is locked, which allows increased wheel speed under severe conditions, such as deep mud.
  • Smooth shifting
    Five-speed transmission with ultra-low first gear features Honda's exclusive Electric Shift Program (ESP) for easy shifts with the touch of handlebar-mounted buttons.
  • Powerful output
    Powerful AC generator has generous capacity with 481 watts of output.
Chassis & Suspension
  • Strong and lightweight
    Durable double-cradle steel frame developed with Computer Aided Engineering is both rigid and lightweight for precise handling and a smoother ride.
  • Great control
    Front and rear suspension both offer 185 mm (7.3 in.) of travel for a plush and controlled ride. Adjustable spring preload on all shocks allows suspension to be tuned to match varying loads and riding conditions.
  • Durable design
    Enclosed-axle swingarm offers optimized stiffness for improved toughness and excellent handling performance.
  • High quality
    Sealed steering-knuckle bearings improve performance with durable, tear-resistant Plastic CV joint boots.
  • Superb comfort
    Rubber swingarm pivot bushings provide excellent low-speed ride comfort and increased durability.
  • Optimal ground clearance
    Generous ground clearance of 191 mm (7.5 in.) allows you to ride over rugged terrain with ease.
  • Impressive power steering
    Electric Power Steering (EPS) reduces steering effort for enhanced manoeuvrability and decreases kickback for improved all-around steering action.
  • Stopping power
    Rear drum brake is located inside the right rear wheel for improved durability and increased ground clearance. Dual front hydraulic disc brakes with large 190 mm rotors provide strong and consistent stopping power.
Additional Features
  • Protective bodywork
    Durable bodywork provides excellent mud and debris protection.
  • Strong visibility
    Twin-headlight system features 35-watt headlights with focused light distribution for improved visibility after dark. Top assist light operates independently of front headlights so it can be turned off while carrying a load on the front carrier.
  • Easy maintenance
    One-piece tank/side cover allows easy access for maintenance with no tools required. The fuel pump derived from Honda automobile technology is mounted in the fuel tank for better heat isolation and increased filter life.
  • Intuitive display
    Full-function instrumentation gives the dash a modern look while providing information at a glance. There’s even a Maintenance Minder system that notifies when it’s time for service.
  • Superior comfort
    Seat padding is both thick and soft for excellent comfort.
  • Added protection
    Full-length synthetic lower skidplate with integrated front brush guard protects against damage from rocks, sticks and other obstacles.
  • Versatile towing ability
    Load capacity for front and rear carriers is 40 kg (88 lbs.) and 80 kg (176 lbs.) respectively. The heavy-duty trailer hitch has a 385 kg (848 lbs.) towing capacity.
  • Multi-functional
    A host of optional accessories allow you to tailor your TRX500 to your needs.
Colours
Vapor White Foreman 500 ES EPS
Vapor White
2017 Foreman 500 ES EPS
MSRP starting from $9,799
MSRP values shown do not include freight and PDI, applicable fees, license, insurance, registration or taxes (all of which may vary by region). Dealer may sell for less. Dealer order/trade may be necessary. See your dealer for details.
Red Foreman 500 ES EPS
Red
2017 Foreman 500 ES EPS
MSRP starting from $9,799
MSRP values shown do not include freight and PDI, applicable fees, license, insurance, registration or taxes (all of which may vary by region). Dealer may sell for less. Dealer order/trade may be necessary. See your dealer for details.
Colours
Vapor White Foreman 500 ES EPS
Vapor White
2017 Foreman 500 ES EPS
MSRP starting from $9,799
Specifications
Engine & Drivetrain
Engine Type
Liquid-cooled longitudinally mounted single-cylinder 4-stroke
Displacement
475 cc
Bore & Stroke
92 mm x 71.5 mm
Compression Ratio
9.5:1
Valve Train
OHV, 2 valves
Fuel Delivery
PGM-FI electronic fuel injection
Transmission
Five-speed with automatic clutch, selectable Electric Shift Program (ESP), reverse and ultra-low first gear
Power Steering
Standard
Final Drive
2WD/4WD; direct front and rear driveshafts with switchable 2WD/4WD and torque-sensing/locking front differential
Front Suspension
Independent double-wishbone with adjustable hydraulic shocks; 185 mm (7.3 in.) travel
Rear Suspension
Swingarm with single adjustable hydraulic shock; 185 mm (7.3 in.) travel
Tires
Front: 25 x 8 - 12 Rear: 25 x 10 - 12
Brakes
Front: dual 190 mm hydraulic discs Rear: 160 mm sealed mechanical drum
Length
2,103 mm (82.8 in.)
Width
1,205 mm (47.4 in.)
Ground Clearance
190 mm (7.5 in.)
Seat Height
869 mm (34.2 in.)
Wheelbase
1,268 mm (49.9 in.)
Curb Weight
294 kg (648 lbs.) including required fluids and full tank of gas - ready to ride
Fuel Capacity
14.7 litres, including 4.9-litre reserve
Colour
Red, Vapor White
Warranty
12 months, unlimited mileage, freely transferable warranty; extended coverage available with Honda Plus
